Mexen PEX-P Compression Connector, Pressed PEX 20 x 3/4 GW x 20 - W97132-2034F20-00

Mexen PEX-P Compression Connector, Pressed PEX 20 x 3/4 GW x 20 - W97132-2034F20-00

  • New
Mexen PEX-P Compression Connector, Pressed PEX 20 x 3/4 GW x 20 - W97132-2034F20-00
search
  • Mexen PEX-P Compression Connector, Pressed PEX 20 x 3/4 GW x 20 - W97132-2034F20-00
  • Mexen PEX-P Compression Connector, Pressed PEX 20 x 3/4 GW x 20 - W97132-2034F20-00
Mexen PEX-P Compression Connector, Pressed PEX 20 x 3/4 GW x 20 - W97132-2034F20-00
Mexen PEX-P Compression Connector, Pressed PEX 20 x 3/4 GW x 20 - W97132-2034F20-00 Mexen PEX-P Compression Connector, Pressed PEX 20 x 3/4 GW x 20 - W97132-2034F20-00

Mexen PEX-P Compression Connector, Pressed PEX 20 x 3/4 GW x 20 - W97132-2034F20-00

Technical data:

Connection diameter 1: 20 mm

Connection diameter 2: 3/4" GW

Connection diameter 3: 20 mm

Body: Brass with nickel plating

Ring: PE

Sleeve: Stainless steel 304

O-rings: NBR

For jaw type: U

Operating temperature: max 95 °C

Maximum working pressure: 10 bar

Inspection window ensures the pipe is fully inserted into the fitting

Serial
Type
Trójnik
Średnica przyłącza 1
20 mm
Średnica przyłącza 2
3/4" GW
Średnica przyłącza 3
20 mm
