Mexen PEX-P reduction press fitting tee, crimped PEX 20 x 16 x 16 - W97131-201616-00

The Mexen PEX-P reduction press fitting tee is an excellent choice for water and heating installations. You will certainly appreciate its nickel-plated brass body and corrosion-resistant stainless steel 304 components. Crimping components such as the PE ring and NBR O-rings ensure connection tightness. The product supports temperatures up to 95 °C and pressure up to 10 bar. The inspection window allows precise installation, ensuring safety and durability of the system.

Technical data:

Connection diameter 1: 20 mm

Connection diameter 2: 16 mm

Connection diameter 3: 16 mm

Body: Nickel-plated brass

Ring: PE

Sleeve: Stainless steel 304

O-rings: NBR

For jaw type: U

Operating temperature: max 95 °C

Maximum operating pressure: 10 bar

Inspection window ensures that the pipe is fully inserted into the fitting

Innovative solutions used in this product

Brass

The product is made using high-quality brass, which is characterised by exceptional durability. Brass is resistant to moisture and corrosion, maintaining its good appearance and high functionality for a long time.

1 Mpa

The product is designed to operate in installations where the working pressure can be up to 1 Mpa (10 bars). This is an important parameter that ensures proper and safe operation in systems with relatively high pressure.

Resistance to high temperature

The product is characterised by extraordinary resistance to high temperatures, not deforming even with prolonged exposure to hot water. The material is also resistant to damage and cracks caused by sudden temperature changes.

10 years warranty

The product is covered by a 10-year warranty. If you encounter any issues with the purchased product, we encourage you to contact us via the contact form or by phone through the helpline number.

PZH Hygiene Certificate

The product holds a certificate issued by the National Institute of Hygiene, confirming compliance with safety standards - it indicates that it does not adversely affect human health or the natural environment in any way. nr B.BK.60110.1255.2024 valid until 27.03.2028

Series
PEX-P
Type
Reducer T-junction
Connector Diameter 1
20 mm
Connector Diameter 2
16 mm
Connection Diameter 3
16 mm
Warranty conditions
Download
PZH Certificate
Download
Safety information
Download
Installation instructions
Download
Manufacturer
See
