Mexen G00 angled thermostatic set with R cover, Duplex, DN50, anthracite - W907-900-905-66

Mexen G00 angled thermostatic set with R cover is an excellent solution for your heating system. Made of high-quality brass, it ensures durability and reliability. The elegant anthracite colour perfectly complements modern interiors. The valve has a G 1/2" connection diameter and a temperature adjustment range from 0 to 29 °C, allowing for precise adjustment of heating conditions. The product is extremely functional thanks to the possibility of connecting the head from either the left or right side.

Technical data:

Valve material: Brass

Valve colour: Anthracite

Valve connection diameter: G 1/2"

Operating temperature: max 120 °C

Maximum working pressure: 10 bar

Supply and shut-off radiator valve

Bottom connection at a spacing of 50 mm

Head thread: M30 x 1.5 mm

Head colour: Anthracite

Adjustment scale: 0-5

Temperature adjustment range: 0-29 °C

Ambient temperature: max 50 °C

Frost protection at 5°C

Possibility to connect the head from the left or right side of the valve

Cover colour: Anthracite

Rosette material: Stainless steel

Rosette width: 115 x 65 mm

Rosette height: 7 mm

Inner hole diameter: 21 mm

Spigot material: Brass

Spigot length: 50 mm

Inner diameter of the spigots: 20 mm

Spacing of radiator connection holes: 50 mm

The cover consists of two single rosettes and a sleeve

Additional fittings for 16x2 mm multilayer pipes and 15 mm copper pipe fittings included

Innovative solutions used in this product

Brass

Making valves from brass ensures their durability, resistance to corrosion, and strength, which is particularly important in environments where there is constant contact with water under pressure and varying temperatures.

Frost Protection

The product features a built-in frost protection function when the temperature drops below 5°C. This function provides protection for the heating system and pipes against freezing, especially during periods of low temperatures when the building is not in use.

Temperature Regulation

The head with a 5-stage temperature regulation scale, ranging from 0-29 °C, allows for precise temperature control. This function enables the user to set the room temperature, which translates to thermal comfort and energy savings.

1 Mpa

The product is designed to operate in installations where the working pressure can be up to 1 Mpa (10 bars). This is an important parameter that ensures proper and safe operation in systems with relatively high pressure.

Immunity and Durability

Set with a stainless steel rosette and brass sleeve combines two materials with exceptional properties. Stainless steel provides an aesthetic finish and resistance to corrosion, while brass guarantees durability and strength when connecting the elements of the heating system.
