Mexen G00 angled thermostatic set with cover S, Duplex, DN50, white - W907-900-910-20

Mexen G00 angled thermostatic set with cover S, Duplex, DN50 in white is the ideal solution for modern heating installations. Made of high-quality brass, it guarantees durability and reliability. It features a maximum working pressure of 10 bar and an operating temperature of up to 120°C. The radiator valve has a bottom connection with 50 mm spacing and the ability to regulate the temperature from 0 to 29°C. Additionally, the product is equipped with a stainless steel cover, which emphasizes its elegant appearance.

Technical data:

Valve material: Brass

Valve colour: White

Valve connection diameter: G 1/2"

Operating temperature: max 120 °C

Maximum working pressure: 10 bar

Radiator supply and shut-off valve

Bottom connection with 50 mm spacing

Head thread: M30 x 1.5 mm

Head colour: White

Regulation scale: 0-5

Temperature regulation range: 0-29 °C

Ambient temperature: max 50 °C

Frost protection 5°C

Possibility of head connection from the left or right side of the valve

Cover colour: White

Rosette material: Stainless steel

Rosette width: 115 x 65 mm

Rosette height: 7 mm

Internal hole diameter: 21 mm

Sleeves material: Brass

Sleeves length: 50 mm

Internal diameter of sleeves: 20 mm

Spacing of radiator connection holes: 50 mm

The cover consists of a double rosette and two sleeves

Includes additional connectors for multilayer pipes 16x2 mm and connectors for copper pipes 15 mm

Innovative solutions used in this product

Brass

Making valves from brass ensures their durability, resistance to corrosion, and strength, which is particularly important in environments where there is constant contact with water under pressure and varying temperatures.

Frost Protection

The product features a built-in frost protection function when the temperature drops below 5°C. This function provides protection for the heating system and pipes against freezing, especially during periods of low temperatures when the building is not in use.

Temperature Regulation

The head with a 5-stage temperature regulation scale, ranging from 0-29 °C, allows for precise temperature control. This function enables the user to set the room temperature, which translates to thermal comfort and energy savings.

1 Mpa

The product is designed for use in installations where the working pressure can be up to 1 Mpa (10 bars). This is an important parameter that ensures proper and safe operation in systems with relatively high pressure.

Immunity and Durability

Set with a stainless steel rosette and brass sleeve combines two materials with exceptional properties. Stainless steel provides an aesthetic finish and resistance to corrosion, while brass guarantees durability and strength when connecting the elements of the heating system.

2 years warranty

This product is covered by a 2-year warranty. If you encounter any problems with the purchased product, we encourage you to contact us via the contact form or by phone on the helpline.

Serial
G00
Type
Angular
Colour
White
Connection diameter
G 1/2"
Cover
Yes
