Mexen AL-O pipe PE-RT/AL/PE-RT 32 x 3 mm, 50 m - W97107-2632-50

The Mexen AL-O PE-RT/AL/PE-RT 32 x 3 mm pipe is an extremely versatile product ideal for central and underfloor heating systems as well as for the distribution of cold and hot water. With a length of 50 m and an external diameter of 32 mm, this pipe provides excellent heat conduction with a coefficient of 0.43 W/(m²K). The high thermal resistance of the polyethylene used here and the operating pressure up to 10 bar ensure reliability even in demanding conditions. 100% diffusion resistance and fire resistance class E additionally enhance its safety and durability.

Technical data:

Length: 50 m

External diameter: 32 mm

Wall thickness: 3 mm

Intermediate layer thickness: 0.3 mm

Outer layer: Polyethylene with increased thermal resistance

Inner layer: Polyethylene with increased thermal resistance

Maximum operating pressure at 20°C: 10 bar

Resistance to gas penetration and corrosion: 100% diffusion resistance

Coefficient of linear expansion: 0.024mm/(m•K)

Thermal conductivity: 0.43 W/(m²K)

Reaction to fire: Class E

Minimum manual bending radius: 160 mm

Minimum bending radius using a spring: 112 mm

Application:

- central heating

- underfloor heating

- cold and hot water supply

Innovative solutions used in this product

100% Anti-Diffusion

The pipe features a special layer that blocks the penetration of oxygen into the interior of the installation. This prevents corrosion of metal components in the heating system, such as radiators or heat exchangers. Such a pipe is particularly recommended for central heating and underfloor heating installations.

Versatile application

The product is used in water supply installations for transporting cold and hot drinking water, as well as in central heating systems. They are also used in industrial installations for transporting chemically aggressive liquids and in air conditioning systems.

Resistance to high temperature

The product is characterised by extraordinary resistance to high temperatures, not deforming even with prolonged exposure to hot water. The material is also resistant to damage and cracks caused by sudden temperature changes.

10 years warranty

The product is covered by a 10-year warranty. If you encounter any issues with the purchased product, we encourage you to contact us via the contact form or by phone through the helpline number.

PZH Hygiene Certificate

The product has a certificate issued by the National Institute of Hygiene, confirming compliance with safety standards - indicating that it does not adversely affect human health or the natural environment in any way. nr B.BK.60110.1252.2024 valid until 31.03.2028

Series
AL-O
Length
50 m
Diameter
32 mm
Type
Pipe
