Mexen G03 angled thermostatic set, nickel - W913-012-938-01

The Mexen G03 angled thermostatic set, nickel, is a reliable choice for your heating system. Made from brass, it ensures durability, while the elegant nickel finish provides a stylish look. The connection diameter of G 1/2" and head thread of M30 x 1.5 mm ensure compatibility with most installations. The set operates at high temperatures up to 120 °C and a maximum working pressure of 10 bar. The adjustment scale of 0-5 and temperature range of 0-29 °C allow for precise control, and the frost protection safeguards the system in winter. The set includes feed and shut-off radiator valves.

Technical data:

Valve material: Brass

Valve color: Nickel

Valve connection diameter: G 1/2"

Operating temperature: max 120 °C

Maximum working pressure: 10 bar

Head thread: M30 x 1.5 mm

Head color: White

Adjustment scale: 0-5

Temperature adjustment range: 0-29 °C

Ambient temperature: max 50 °C

Frost protection 5°C

Included in the set are feed and shut-off radiator valves

Innovative solutions used in this product

Brass

Making valves from brass ensures their durability, resistance to corrosion, and strength, which is particularly important in environments where there is constant contact with water under pressure and varying temperatures.

Frost Protection

The product features a built-in frost protection function when the temperature drops below 5°C. This function provides protection for the heating system and pipes against freezing, especially during periods of low temperatures when the building is not in use.

Temperature Regulation

The head with a 5-stage temperature regulation scale, ranging from 0-29 °C, allows for precise temperature control. This function enables the user to set the room temperature, which translates to thermal comfort and energy savings.

1 Mpa

The product is designed to operate in installations where the working pressure can be up to 1 Mpa (10 bars). This is an important parameter that ensures proper and safe operation in systems with relatively high pressure.

2 years warranty

This product is covered by a 2-year warranty. If you encounter any problems with the purchased product, we encourage you to contact us via the contact form or by phone on the helpline.

Series
G03
Type
Angle
Color
Nickel
Inlet Diameter
G 1/2"
Cover
No
User manual - radiator valve
Download
User manual - thermostatic head
Download
Safety Information - Radiator Valve
Download
Safety information - thermostatic head
Download
Warranty conditions
Download
